Form No. 8P95-EA-00G
Driving Your Mazda
5-9
045-1AE
Automatic Transaxle
■ Automatic Transaxle Controls
Various Lockouts:
Indicates that you must depress the brake pedal
and, hold in the lock-release button to shift
(The ignition switch must be in the ACC or ON position.)
The shift lever can be shifted freely into any position
indicated by the arrow.
Lock-release button
To prevent unsafe shifting
Shift pattern indicator
Shows shift lever position
Shift lever
Overdrive button
For selecting either a three-speed or four-speed transaxle
Overdrive (O/D) OFF
indicator
This indicator comes on
when the overdrive has
been turned off.
J94A4007
J94A4006_a
Indicates that you must hold in the lock-release button to shift.
J94S.J94A4006_a+7
