Form No. 8P95-EA-00G
Driving Your Mazda
5-66
J94AAC10
▼ Fan control dial
This dial allows variable fan speeds.
0 — Fan off
1 — Low speed
2 — Medium low speed
3 — Medium high speed
4 — High speed
Cold Hot
J94AAC11
▼ Temperature control dial
This dial controls temperature of the
air coming through the system. Turn it
clockwise for hot (red) and
counterclockwise for cold (blue).
