Form No. 8P95-EA-00G
Maintenance
8-47
J94A7031
4. Disconnect the electrical connector
from the bulb by squeezing the tabs
and pulling it to the rear.
Sealing
cover
Bulb
retaining
spring
J94A7032
5. Pull off the sealing cover.
6. Unhook the bulb retaining spring.
7. Swing the retaining spring out and
away to free the headlight bulb.
8. Carefully remove the headlight
bulb from the socket by pulling it
straight back.
9. Replace the bulb.
10. Install in the reverse order of
removal.
NOTE
Use the protective cover and
carton to dispose of the old bulb
promptly out of the reach of
children.
