McCain 2070LX User Manual

4
1.4 STANDARD FEATURES
Operating system
Linux, Version 2.6.22
Modules (standard, included)
2070-1C CPU Module
2070-2E+ Field I/O module
2070LX Front Panel Module
2070-4A Power Supply
Microprocessors
MPC8360E Freescale PowerQUICC II Pro microprocessor
Backup real-time clock (RTC)
Maxim DS1390
Memory
256 MB DRAM
16 MB Flash Memory NOR
256 MB Flash Memory NAND
2 MB non-volatile SRAM
Applicable standards
Meets or exceeds Caltrans TEES 2009 standard
1.5 INTERFACES
Communication interfaces
Up to five SDLC ports
Up to seven asynchronous ports
ENET 1: 100 Base-T Ethernet switch, 1 uplink and 3 additional ports
ENET 2: 100 Base-T Ethernet port dedicated for local communications (i.e. laptop or similar)
One USB port
Front panel interface
Display: 8 lines x 40 characters
Keyboards: 3 x 4 navigation and 4 x 4 data entry keypads
Cabinet interfaces
C11S Connector
C12S Connector
C1S Connector
