Instructions for Display of Hazard and Infor-
mational Signs
• It is the responsibility of the customer to know the
lighting and marking requirements of the local
highway authorities and to install and maintain
the equipment to provide compliance with the
regulations. Add extra lights when transporting at
night or during periods of limited visibility.
• Keep safety signs clean and legible at all times.
Replace safety signs that are missing or have
become illegible.
• Do not paint over, remove, or deface any safety signs
or warning decals on your equipment. Observe all
safety signs and practice the instructions on them.
• Replacement parts that display a safety sign should
display the same sign.
• Make sure the hazard warning labels or other
information decals are legible and attached to the
unit before use.
• Safety signs are available from your Distributor,
Dealer Parts Department, or the factory.
MFM-00054
DOWN
1 Turn = 1/2”
Deeper
A B C D E F G
Each mark represents a 1” change in disk depth.
NOTICE
READ AND UNDERSTAND THE OPERATOR’S
MANUAL BEFORE USING.
TRANSPORT LOCKUPS AND WING LOCK
PINS MUST BE USED DURING TRANSPORT.
DO NOT RUN THE DISK GANGS TO A DEPTH
GREATER THAN 4 (FOUR) INCHES.
MAXIMUM FIELD TRAVEL SPEED IS 9 MPH.
DC-231
DC-300
DC-224
DC-225
DC-297 (left, shown)
DC-298 (right)
DC-230
DC-306
