McFarlane 4100 Series - Disk Gang Hydraulics for RD-4145

Reel Disk from McFarlane Mfg. 88 800-627-8569
Disk Gang Hydraulics for RD-4145
2
1
5
MFM-0134
7
8
9
4
1
1
7
8
3
3
6
8
2
3
4
3
6
7
5
8
3
Item Part Number Description
1 HYF-2820 HYD ELBOW, 3/8M - 1/2 MORB
2 HYH-1045 HYD HOSE, 3/8 x 100 (90/STD)
3 HYF-1809 HYD TEE, 3/8M - 1/2 MORB - 3/8M
4 HYS-2009 HYD HOSE COVER, 90
5 HYH-1048 HYD HOSE, 3/8 x 125 (90/STD)
6 HYH-1044 HYD HOSE, 3/8 x 96 (90/STD)
7 HYH-1043 HYD HOSE, 3/8 x 85 (90/STD)
8 HYS-2007 HYD HOSE COVER, 70
9 HYH-1040 HYD HOSE, 3/8 x 76 (90/STD)
