Reel Disk from McFarlane Mfg. 14 800-627-8569
NOTICE
READ AND UNDERSTAND THE OPERATOR’S
MANUAL BEFORE USING.
TRANSPORT LOCKUPS AND WING LOCK
PINS MUST BE USED DURING TRANSPORT.
DO NOT RUN THE DISK GANGS TO A DEPTH
GREATER THAN 4 (FOUR) INCHES.
MAXIMUM FIELD TRAVEL SPEED IS 9 MPH.
A B C D E F G
ļ Each mark represents a 1” change in disk depth.
1 Turn = 1/2”
Deeper
Assembly
Refer to the separate Reel Disk Assembly manual for
complete assembly instructions.
The assembly process consists of attaching the hitch to
the main frame and attaching the lift arm/rolling basket
subassemblies to the frame. The approximate time
required is 1 to 2 hours for 12’, 14’, and 16’ models, 2 to 3
hours for 20’ through 30’ models and 3 to 4 hours for 35’
and 45’ models.
