McFarlane 4100 Series - Center Wavy Disk for RD-4100 Series

Reel Disk from McFarlane Mfg. 66 800-627-8569
Center Wavy Disk for RD-4100 Series
1 2 3
12
11
10
9 8
7
6
5
4
Item Part Number Description
1 BH-6325 5/8-11 x 2-1/2 HHCS GD 5
2 RD-4432 SPRING CLAMP
3 NLT-6311 5/8-11 TOP LOCK NUT
4 RD-4919 SPACER PLATE
5 BH-6335 5/8-11 x 3-1/2 HHCS GD 5
6
BHF-5013 HUB BOLT 1/2-20 x 1-1/4
7 RD-5092 HUB RETAINER
8 QT-1026 HUB PLATE
9 RD-4265 CENTER DISK, WAVY
10 HD-1170 HUB ASSY
11 RD-4886 CENTER DISK MOUNT
12 QT-1027 DISK SPRING
