800-627-8569 45 Reel Disk from McFarlane Mfg.
Hitch Frame for RD-4100 Series (continued)
Item Part Number Description
1
RD-4411
RD-4409
RD-4418
HITCH, 4 X 6 (4112-4114)
HITCH, 4 X 6 (4116-4130)
HITCH, 6 X 6 (4135-4145)
2 RT-2107 HINGE PIN, 1-1/2 X 9-5/8
3
BHY-5635 9/16-12 X 3-1/2 GRADE 8 BOLT
4 NLT-5612 9/16-12 TOP LOCK NUT
5 RT-2112 PIVOT END TURNBUCKLE, 3 7/8” DOM
6 RT-3145 HITCH TURNBUCKLE - 30"
7 RT-2111 HITCH END TURNBUCKLE, 2 EAR
8 RT-2114 TURNBUCKLE LOCK, 3"
9 BH-5028 1/2 X 2-3/4 GRADE 5 HEX BOLT
10 RT-2113 TURNBUCKLE PIN - 1-1/4 X 5-1/4
11 RD-4309 HYDRAULIC HOSE RACK CLAMP
12 BH-4420 7/16 X 2 HEX BOLT
13 NLT-4414 7/16 TOP LOCK NUT
14 LW-0025 1/4 LOCK WASHER
15 NH-2520 1/4 HEX NUT
16 PH-8860 HITCH PIN, 7/8 x 6 w/#6 BRIDGE PIN
17 RT-2416 TURNBUCKLE WRENCH, 1-1/4"
18 LB-1110 LIGHT PLUG STORAGE
19 BH-2510 1/4 X 1 HEX BOLT
20 RD-4308 HYDRAULIC HOSE RACK
21 NLT-1008 1” TOP LOCK NUT
22
PPI-300
PPI-400
HITCH BASE CAT III (4112-4120)
HITCH BASE CAT IV (4125-4145)
23 BHY-1070 1 X 7 GRADE 8 HEX BOLT
24
CH-1816
CH-1820
CH-1830
SAFETY CHAIN, 16,100lbs (4112-4130)
SAFETY CHAIN, 20,200lbs (4135)
SAFETY CHAIN, 30,400lbs (4145)
25 RT-2054 BUSHING, 1 7/8"OD X 1-1/4"ID X 1"
26 RT-3103 SAFETY CHAIN WASHER
27 BHY-1085 1 X 8-1/2 GRADE 8 HEX BOLT
28 RT-3144 JACK, SQ-15", 2000#
29
BU-1265
BU-1267
1/2 X 6 X 5 U-BOLT (4112-4120)
1/2 X 6 X 7-1/4 U-BOLT (4125-4145)
30 RD-4306 DOCUMENT TUBE
31 MM-1204 4” HOSE CLAMP
32 NLT-5013 1/2-13 TOP LOCK NUT
33 RT-2124 LEVEL LIFT TUBE PIN
34 NLT-5013 NUT, LOCK, HEX, 1/2-13
