Main Frame Axle for RD-4112, 4114, 4116, 4120, 4125 and 4130 (continued)
Item Part Number Description
1 RD-4361 MAIN AXLE CYLINDER ARM
2 HYO-2103 CYLINDER CLEVIS PIN, 1 X 3
3 CP-3620 3/16 X 2 COTTER PIN
4
NLT-1008 1-8 TOP LOCK NUT
5 BHY-1033 1-8 X 3-1/4 GRADE 8 HEX BOLT
6 RD-4360 MAIN AXLE CYLINDER TRUSS
7 BHY-1065 1-8 X 6-1/2 GRADE 8 HEX BOLT
8 HYS-1102 CYLINDER LOCK, RD TRANSPORT
9 HYS-1112 1-8 X 5 GRADE 8 HEX BOLT W/PIN HOLE
10 NCJ-1008 1” CASTLE JAM NUT
11 BH-6320 5/8-11 X 2 GRADE 5 HEX BOLT
12 LW-0063 5/8 LOCK WASHER
13 NH-6311 5/8-11 HEX NUT
14
RD-4626
QT-1133
QT-1132
AXLE MOUNT BRACKET
AXLE MOUNT INSERT
AXLE MOUNT CAP
15
RD-5047
RD-5048
RD-4983
RD-5049
RD-5050
MAIN AXLE ASSEMBLY (4112)
MAIN AXLE ASSEMBLY (4114)
MAIN AXLE ASSEMBLY (4116)
MAIN AXLE ASSEMBLY (4120)
MAIN AXLE ASSEMBLY (4125-4130)
16 BH-5045 1/2” - 13 X 4-1/2 HEX BOLT
17 NLT-5013 1/2” - 13 TOP LOCK NUT
18
WDL-2505
RT-2170
RT-3180
SPINDLE, 1 ¾ X 9 ½ (4112-4116)
SPINDLE, 2 ¼ X 11 ½ (4120)
SPINDLE, 2 ¾ X 12 ½ (4125-4130)
19
1
HD-1371
RT-2171
RT-3181
6 BOLT HUB ASSEMBLY, 3560 LB (4112-4116)
8 BOLT HUB ASSEMBLY, 4500 LB (4120)
8 BOLT HUB ASSEMBLY, 6000 LB (4125-4130)
20
11L-15 8T
12.5L-15 10T
12.5L-15 12T
12.5L-15 18T
TIRE ONLY, 11L – 15, 8 PLY (4112-4116)
TIRE ONLY, 12.5L – 15, 10 PLY (4120)
TIRE ONLY, 12.5L – 15, 12 PLY (4125)
TIRE ONLY, 12.5L – 15, 18 PLY (4130)
21
HD-1368
RT-2179
RIM, 15 X 8, 6-BOLT, 2900 LB (4112-4116)
RIM, 15 X 10, 8 BOLT, 5000 LB (4120-4130)
22
RD-4587
RD-4588
RD-4646
RD-4589
RD-4590
MAIN FRAME (4112)
MAIN FRAME (4114)
MAIN FRAME (4116)
MAIN FRAME (4120)
MAIN FRAME (4125-4130)
23 WN-0063
WB-5010
WHEEL NUTS 5/8
WHEEL BOLT-1/2 x 1-3/4
24 HYS-1103 CYLINDER LOCK HANDLE
25 QT-1133 AXLE MOUNT INSERT
26 QT-1173 AXLE MOUNT INSERT, SPLIT
1
See hub diagram for details
