800-627-8569 53 Reel Disk from McFarlane Mfg.
Main Frame Axle for RD-4135 and 4145 (continued)
Item Part Number Description
1
RD-4361
RD-4637
MAIN AXLE CYLINDER ARM (4135)
MAIN AXLE CYLINDER ARM (4145)
2 HYO-2103 CYLINDER CLEVIS PIN, 1 X 3
3
CP-3620 3/16 X 2 COTTER PIN
4 NLT-1008 1-8 TOP LOCK NUT
5 BHY-1033 1-8 X 3-1/4 GRADE 8 HEX BOLT
6 RD-4360 MAIN AXLE CYLINDER TRUSS
7 BHY-1065 1-8 X 6-1/2 GRADE 8 HEX BOLT
8 HYS-1102 CYLINDER LOCK, RD TRANSPORT
9 HYS-1112 1-8 X 5 GRADE 8 HEX BOLT W/PIN HOLE
10 NCJ-1008 1” CASTLE JAM NUT
11 BH-6320 5/8-11 X 2 GRADE 5 HEX BOLT
12 LW-0063 5/8 LOCK WASHER
13 NH-6311 5/8-11 HEX NUT
14
RD-4626
QT-1133
QT-1132
AXLE MOUNT BRACKET
AXLE MOUNT INSERT
AXLE MOUNT CAP
15
RD-5051
RD-5053
MAIN AXLE ASSEMBLY (4135)
MAIN AXLE ASSEMBLY (4145)
16
RD-4433
RD-4715
CARRIAGE COVER PLATE (4135)
CARRIAGE COVER PLATE (4145)
17 BH-3860 3/8-16 X 6 GRADE 5 HEX BOLT
18 NLT-3816 3/8-16 TOP LOCK NUT
19
RD-4992
RD-4995
MAIN FRAME (4135)
MAIN FRAME (4145)
20 BH-7550 3/4-10 X 5 GRADE 5 HEX BOLT
21 NLT-7510 3/4 TOP LOCK NUT
22 RD-4644 AXLE CARRIAGE PIVOT PIN
23
RD-4413
RD-4642
AXLE CARRIAGE ASSEMBLY (4135)
AXLE CARRIAGE ASSEMBLY (4145)
24 BH-5050 1/2-13 X 5 HEX BOLT
25 NLT-5013 1/2-13 TOP LOCK NUT
26
RT-3180
RD-4416
SPINDLE, 2-3/4 X 12-1/2 (4135)
SPINDLE, 3 X 12-1/2 (4145)
27
RT-3181
RD-4580
8 BOLT HUB ASSEMBLY, 6000 LB (4135)
8 BOLT HUB ASSEMBLY, 7500 LB (4145)
28
12.5L-15 FT
36x16-17.5 14T
TIRE ONLY, F PLY HWY (4135)
TIRE ONLY, 14 PLY (4145)
29
RT-2179
RD-4645
RIM, 15 X 10, 8 BOLT, 5000 LB (4135)
RIM, 17.5 X 10.5, 8-BOLT, 8000 LB (4145)
30 WN-0063 WHEEL NUTS 5/8
31 QT-1173 AXLE MOUNT INSERT SPLIT
32 QT-1133 AXLE MOUNT INSERT
33 HYS-1103 LOCK HANDLE
34 RD-4643 SPRING BUSHING
35 GZ-2528 GREASE ZERK
