McHale 991 High Speed Round Bale Wrapper
32
5.4 Connecting the control box
The electronic control box must be located inside the tractor cab in the operator’s field
of vision and within easy reach of the red emergency stop button. (See ‘Electronic
control system’). Secure the control unit in the tractor cab, using the V-brackets and
fasteners provided. The male half attaches to the control box and the female half
attaches to the tractor cab allowing for quick placement/removal, every time it is used.
Ensure that the cable to the machine is not under tension and not near sharp edges,
etc. The electric power supply is obtained from the socket of the tractor.
Connect the supplied fused electric power lead to the tractor battery ensuring to route
away from sharp edges and hot surfaces. The control box is not waterproof, it must be
protected from rain.
CAUTION: Do not connect the control box to a 24 V power supply
Do not attempt to connect the control box to a 24 V power supply, as
machine component damage will result.
