McHale 991 High Speed Round Bale Wrapper
36
7
Electronic control system
(Software Version EXS300-025)
7.1 Electronic control box
The electronic control box is the main interface between the operator and the machine.
When the machine is in fully automatic mode, settings must be selected before
wrapping commences. It is also possible to work the machine manually through the
buttons on the control box.
Remote control
receiver
1
2
3
4
5
6
