McHale 991 High Speed Round Bale Wrapper
9
2.3 General specifications
Units are given in both metric and UK imperial values, with the latter shown in brackets.
*Check with national road traffic regulations in the individual country!
2.4 Tractor specifications
2.5 Machine specifications
Transport length 5.7 m (18’ 8”)
Transport width 2.45 m (8’ 0”)
Transport height 2.46 m (8’ 1”)
Height to top of rollers 1.25 m (4’ 1”)
Transport weight (unladen) 2,125 kg (4,685 lbs)
Axle weight (unladen) 1,900 kg (4,189 lbs)
Maximum road speed* 40 km/h (25 mph)
Attachment Pin hitch
Towing tractor requirements 35 kW (47 hp)
Electrics 12 V DC, 7 A approx.
Hydraulic systems Open-centre, closed-centre, load-sensing
Minimum hydraulic pressure 170 bar (2,465 psi)
Minimum hydraulic flow rate 22 l/min (4.8 gal/min)
Maximum rotary table speed 30 rpm
Film stretch 70% (64% or 55% optional)
Film layers 2+2 system
Film width 750 mm
Maximum bale size 1.5 m (4’ 9”)
Maximum bale weight 1,000 kg (2,205 lbs)
