McHale F5500 - Rotor duplex chain adjustment

McHale F5500 Baler
104
9.18.4 Rotor duplex chain adjustment
To adjust the duplex chain the following tools are required; two 24 mm spanners.
1. Hold the lower nut and loosen the upper nut.
2. To tighten - screw down the lower nut in the direction (T).
3. When the chain is at the required tension, screw down the upper nut.
4. Lock the two nuts together to secure in place.
L
T
Upper nut
Lower nut
