McHale F5500 Baler
54
Oil pump adjustment
Once adjustment is complete, screw the black plastic cover back on top of the pump
unit. Oil delivery should continue to be monitored and readjusted, if necessary, until
desired results are achieved.
6.8 Gearbox oil
The gearbox is located to the rear of the PTO shaft. Your machine will be fitted with
either a 540 rpm or a 1,000 rpm gearbox. Oil quantities and filler ports are different for
the different size gearboxes. The 1,000 rpm gearbox has a sight glass for checking the
oil level whereas the 540 rpm gearbox has a dipstick on the removable filler breather
plug.
WARNING: Ensure the tractor is shut down before changing oil
Ensure that the tractor engine has been shut down, the key has been
removed from the ignition and the brakes have been applied before
changing oil. The PTO shaft should also be removed.
