McHale F5500 Baler
45
The following table shows the amount of net applied for each specific notch.
*Calculated net settings
Knife frame bar
Knife tripped Knife not tripped (re-set) Net adjustment
Notch (#) Layers of Net* (#) Length of Net* (m)
1 2 7.5
2 2.25 8.5
3 2.5 9.4
4 2.75 10.4
5 3 11.3
6 3.25 12.3
7 3.5 13.2
8 3.75 14.2
NOTE: Ensure bill hook rests on the adjuster
Always ensure that the bill hook rests on the adjuster, in the knife re-set
position.
