15
The C2500 Default Input Names (CD, AUX, DVD,
etc. as indicated on the Front Panel Display) can be
customized with a different name up to nine charac-
ters long (My Phone, MCD1100, etc.). The available
characters for renaming the input include the follow-
ing: ! < > * , / - _ 0 1 2 3 4 5 6 7 8 9 A B C D E F G H
I K L M N O P Q R S T U V W X Y Z .
In the following example, the AUX Input will be re-
named to “MY-PHONE”.
1. Press and hold the TONE BYPASS/SETUP Push-
button until the Front Panel Display indicates the
Setup Mode is active. Then rotate the INPUT
CONTROL and select the Setup Menu item “SET-
UP: SOURCE NAME, AUX >> AUX”. Refer to
figure 9.
Note: If the AUX Input is not displayed, rotate the
INPUT Control until it is displayed.
2. Press and hold in the TRIM Push-button until the
character “A” of the name AUX starts flashing.
Refer to figure 10.
3. Rotate the VOLUME/ADJUST Control until the
character “M” appears. Refer to figure 11.
Source Input Renaming
Default Input Name New Input Name
TUNER
CD
CD2
DVD
AUX
SERVER
USB-D/A
PHONO MC
PHONO MM
4. Rotate the INPUT Control until the character “U”
starts flashing. Refer to figure 12.
5. Rotate the VOLUME/ADJUST Control until the
character “Y” appears. Refer to figure 13.
6. Repeat steps 3 thru 5 until the new name of “MY-
PHONE” is indicated on the Front Panel Display.
Refer to figure 14.
7. To save the new Input Name press and hold in the
TRIM Push-button until the word SAVED appears
momentarily on the Front Panel Display. Refer to
figure 15.
Note: When direct accessing the “MY-PHONE”
Input using the Remote Control, press the AUX
Pushbutton.
Record any changes made to the various default Input
Names in the following chart for future reference.
8. To exit from the Setup Mode, press the TONE
BYPASS Push-button and the Front Panel Display
will revert back to its normal display.
Figure 9
