McIntosh C2500 User Manual

18
5. Rotate the VOLUME/ADJUST Control until “Ac-
tion: SOURCE” appears. Refer to figure 29.
6. Then press the OUTPUT 2 / MENU ► Push-
button until the Setup Menu item “SETUP: TRIG1
OUTPUT, Source: _ _ _ _ _ _ _ _ OFF” appears
on the Front Panel Display. Refer to figure 30.
Notes: 1. The Input Source selected before entering
the Setup Mode will be display in step six/
figure 30.
2. By default all the Source Inputs are set to
Off.
3. Any combination of Source Inputs from
one to all may be assigned to either Trig-
ger (1 or 2) or both Triggers.
7. Rotate the INPUT Control to select the Tuner as
the source. Refer to figure 31.
8. Rotate the VOLUME/ADJUST Control until
“Source: Tuner ON” appears. Refer to figure 32.
9. Press the TONE BYPASS/SETUP Push-button to
exit the Setup Mode.
By default the Power Control TRIGger 1 and TRIGger
2 Outputs function the same as the MAIN Power Con-
trol Jack, switching On/Off with the C2500. Trigger 1
and 2 are also reassignable to activate when the ACC
ON/OFF Push-buttons on the Remote Control are
used or when a given Input or Inputs are selected.
EXAMPLE ONE:
The Power Control Trigger 1 Output will be set to
function via the Remote Control ACC Push-buttons.
1. Press and hold the TONE BYPASS/SETUP Push-
button until the Setup Mode is active. Then press
the OUTPUT 2 / MENU ► Push-button until the
Setup Menu item “SETUP: TRIG1 OUTPUT, Ac-
tion: MAIN” appears on the Front Panel Display.
Refer to figure 27.
2. Rotate the VOLUME/ADJUST Control until “Ac-
tion: REMOTE” appears. Refer to figure 28.
3. Press the TONE BYPASS/SETUP Push-button to
exit the Setup Mode.
EXAMPLE TWO:
This example will use selection of the Tuner Input to
switch the Trigger 1 Output On.
4. Press and hold the TONE BYPASS/SETUP Push-
button until the Setup Mode is active. Then press
the OUTPUT 2 / MENU ► Push-button until the
Setup Menu item “SETUP: TRIG1 Output, Ac-
tion: MAIN” appears on the Front Panel Display.
Refer to figure 27.
2. Rotate the VOLUME/ADJUST Control until
“SETUP: PASSTHRU, Source: BALANCED
2” appears on the Front Panel Display. Refer to
figure 26.
3. Press the TONE BYPASS/SETUP Push-button to
exit the Setup Mode.
Figure 29
SETUP: TRIG1 OUTPUT
Action: SOURCE
Figure 31
SETUP: TRIG1 OUTPUT
Source: Tuner OFF
Figure 32
SETUP: TRIG1 OUTPUT
Source: Tuner ON
Power Control Triggers 1 and 2
Figure 27
SETUP: TRIG1 OUTPUT
Action: MAIN
Figure 28
SETUP: TRIG1 OUTPUT
Action: REMOTE
SETUP: PASSTHRU
Source: BALANCED 2
Figure 26
Figure 30
SETUP: TRIG1 OUTPUT
Source: _______ OFF

McIntosh C2500 Specifications

General

Total Harmonic Distortion	0.08%
Signal to Noise Ratio	100dB
Rated Output Voltage	2.5V unbalanced, 5V balanced
Maximum Output Voltage	8V unbalanced, 16V balanced
High Level Voltage Gain	15dB
Type	Vacuum Tube Preamplifier
Inputs	6 unbalanced, 2 balanced, 1 phono MC, 1 phono MM
Outputs	3 unbalanced, 2 balanced
Weight	29 lbs (13.2 kg)
Input Impedance	47k ohms
Phono Voltage Gain	40dB (MM), 60dB (MC)
Frequency Response	+0, -0.5dB from 20Hz to 20, 000Hz +0, -3dB from 10Hz to 100, 000Hz
