MX200
SETUP: SPEAKERS > CROSSOVER
Setting Options
Dependence Independent, All
Independent
Bass Type
Bass LP Filter
from the output to “small” speakers and is sent to the
subwoofer or front speakers. Most small speakers use a
chosen value. Independent will allow each available
SETUP: SPEAKERS > CROSSOVER > BASS TYPE
When the subwoofer mode is set to LFE (Low
of speakers set to small is sent to the subwoofer
of the main channel are sent to the subwoofer.
SETUP: SPEAKERS > CROSSOVER > BASS LP FILTER
chosen option will not be sent to the subwoofer. The
LPF setting does not apply to content sent from the
LFE channel to the subwoofers.
SETUP: SPEAKERS > SPEAKER LEVEL
Setting Options
Test Tone
Front Left
Front Right
Surround Right
Rear Right
Rear Left
Surround Left
Top Left Front*
Top Right Front*
Top Rear Left
Top Rear Right
Subwoofer 1
Subwoofer 2
Note: Some settings are only available on the browser version of
the setup menu these are indicated with an *.
The test tones and levels submenu provides the
ability to manually set relative levels for all speaker
This does not need to be set if using Dirac Live
calibration.
When test tone is set to On, a tone will play through
Dirac Live will automatically set levels and will
setting test tones will replace Dirac Live settings.
Speaker Placement
Speaker Position
Front The Front Left and Right speakers should
position. The distance between each speaker
and your TV should also be about the same.
The Middle speaker should be between the
Front speakers and above or below your TV.
Top Front Mount the Top Front Left and Right speakers
on the ceiling slightly in front of your main
listening position and align with the Left and
Right Front speakers.
Top Middle Mount the Top Middle Left and Right speakers
directly above the main listening position and
align with the Left and Right Front speakers.
Top Rear Mount the Top Rear Left and Right speakers
on the ceiling slightly behind your main
listening position and align with the Left and
Right Front speakers.
Subwoofer Place the Subwoofer at a convenient location
near the Front speakers. If you have two
Subwoofers, place them asymmetrically across
the front of your room.
Front Dolby
speaker
Left/Right
Place the Front Dolby Enabled speakers on
the Front speakers (left and right). For a Dolby
Atmos Enabled speaker integrated with a
Front speaker, place the Dolby Atmos Enabled
speaker instead of the Front speaker.
Surround
Dolby
speaker
Place the Surround Dolby Enabled speaker
on the Surround speaker. For a Dolby Atmos
Enabled speaker integrated with a Surround
speaker, place the Dolby Atmos Enabled
speaker instead of the Surround speaker.
Back Dolby
speaker
Place the Back Dolby Enabled speaker on the
surround back speaker. For a Dolby Atmos
Enabled speaker integrated with a Surround
Back speaker, place the Dolby Atmos Enabled
speaker instead of the Surround Back speaker.
More information about speaker placement can be
Speakers Setup Menu (continued)
