McQuay MicroTech III RAH User Manual

McQuay OM 920-1 29
Keypad/Display Menu Structure
Daily Schedule Menu
The Daily Schedule sets the start and stop times for each of the days of the week. One start and
one stop time can be set for each day.
One Event Schedule Menu
The One Event Schedule is used to set the start and stop times for one event.
Holiday Schedule Menu
The Holiday Schedule is used to set the start and stop times for up to 16 different holidays.
Optimal Start Menu
The Optimal Start menu is used to set up the unit so it starts at the most efficient time before
building occupancy.
Note – Even though these parameters are adjustable, other than perhaps the Design Htg OAT
and the Design Clg OAT they generally do not require adjustment as they will be
automatically adjusted during normal optimal start operation.
Enable is an adjustable item that turns on the optimal start feature. Setting the value to yes
will activate this function.
Table 18: Daily Schedule Menu
Menu Display Name Item Display Name Default Setting Range Password Level
Daily Schedule Mon= 00:00 – 00:00 00:00 – 23:59 6
Tue= 00:00 – 00:00 00:00 – 23:59 6
Wed= 00:00 – 00:00 00:00 – 23:59 6
Thu= 00:00 – 00:00 00:00 – 23:59 6
Fri= 00:00 – 00:00 00:00 – 23:59 6
Sat= 00:00 – 00:00 00:00 – 23:59 6
Sun= 00:00 – 00:00 00:00 – 23:59 6
Hol= 00:00 – 00:00 00:00 – 23:59 6
Table 19: One Event Schedule Menu
Menu Display Name Item Display Name Default Setting Range Password Level
One Event Schedule Beg= 00/00/00 @ 00:00 00/00/00-12/31/99
@ 00:00 – 23:59
6
End= 00/00/00 @ 00:00 00/00/00-12/31/99
@ 00:00 – 23:59
6
Table 20: Holiday Schedule Menu
Menu Display Name Item Display Name Default Setting Range Password Level
Holiday Schedule Hol 1= 00/00/00-00/00/00 00/00/00-12/31/99 6
Hol 2= 00/00/00-00/00/00 00/00/00-12/31/99 6
Hol 3= 00/00/00-00/00/00 00/00/00-12/31/99 6
Hol 4= 00/00/00-00/00/00 00/00/00-12/31/99 6
Hol 5= 00/00/00-00/00/00 00/00/00-12/31/99 6
Hol 6= 00/00/00-00/00/00 00/00/00-12/31/99 6
Hol 7= 00/00/00-00/00/00 00/00/00-12/31/99 6
Hol 8= 00/00/00-00/00/00 00/00/00-12/31/99 6
Hol 9= 00/00/00-00/00/00 00/00/00-12/31/99 6
Hol 10= 00/00/00-00/00/00 00/00/00-12/31/99 6
Table 21: Optimal Start Menu
Menu Display Name Item Display Name Default Setting Range Password Level
Optimal Start Enable= No No 6
Yes
Htg Rate= 0.4°F/min 0.0-1.0°F/min 6
Htg OAT= 35°F -40-60°F 6
Des Htg OAT= 0°F -40-60°F 6
Clg Rate= 0.4°F/min 0.0-1.0°F/min 6
Clg OAT= 85°F -60-140°F 6
Des Clg OAT= 95°F -60-140°F 6
