Transport and Lifting Instructions
Safety Information
This section is provided for reference and does not supersede any
government or company policy regarding the loading, transport or lifting
of MEC machinery.
Truck drivers are responsible for loading and securing machines, and
should be properly trained and authorized to operate MEC machinery.
Drivers are also responsible for selecting the correct and appropriate
trailer according to government regulations and company policy. Drivers
must ensure that the vehicle and chains are strong enough to hold the
weight of the machine (see the serial number plate for machine weight).
While loading and unloading, the transport vehicle must be parked on a
level surface and secured to prevent rolling.
Loading: Free-wheel conguration for Winching or Towing
RUNAWAY HAZARD!
After releasing the brakes there is nothing to stop machine travel.
Machine will roll freely on slopes.
ALWAYS chock the wheels before manually releasing the brakes.
The machine can be winched or towed short distances at speeds not to exceed:
1930SE 0.5 MPH (0.8 km/h)
2632SE, 3346SE, 4046SE, 4555SE 2.5 MPH (4.0 km/h)
Before towing or winching the machine, it is necessary to release the brakes. Reset the brakes after
towing or winching.
Brake Release Operation
1. Chock the wheels to prevent the machine from rolling.
2. Pull out the platform and emergency red Emergency Stop button to the “ON” position.
3. Turn the key switch to the “ground” position while pressing and holding down the “Menu Enter
Button” button on the ECU panel to enter the password input screen.
4. Press the “Menu Enter Button” 4 times to enter the Menu screen.
5. Press either the “Menu Up Button” or “Menu Down Button” button to switch to the Special mode
(“ 4. Special Mode “).
6. Press the “Menu Enter Button” button to display the Special mode. Press either the “Menu Up
Button” or “Menu Down Button” button to switch to the manual push menu (“ 1. Brake Release “).
7. Press “Menu Enter Button” button to display “long press to conrm release of brake”. Press
and hold down the “Menu Enter Button” button to show “Brake Released!” The horn will sound
signaling that all brakes have been released.
