14 Mecmesin MultiTest-dV Operating Manual
4.7. Bolting the Test Stand to the Work Surface
To comply with European regulations and ensure the safe use of the equipment, single
column stands should be secured to the bench as follows:
The extended-length test stands (MultiTest 0.5-dV and MultiTest 1-dV) are supplied
with base anchoring brackets to allow the test stands to be bolted to a bench.
Screw the anchoring brackets to the four positions on the base plate of the MultiTest 0.5-
dV or 1-dV using the M6 screws provided (Shown below). Secure the test stand to the
bench using suitable fasteners.
Test Stand Capacity (kN) Height (Mm) Feet/Fixing Supplied Bolting Recommended
