MultiTest-dV Operating Manual Mecmesin  31
7. MultiTest-dV Settings
7.1. MultiTest-dV Settings – dV Operation
The settings listed below are for a MultiTest-dV being used in dV mode, for dV(u)
operation see 7.2.
Settings: Jog settings
Within the jog settings menu, you can configure the jog speed limits while in jog mode.
Below is a detailed breakdown of each setting and the options available for each setting.
Setting Action Range
Up Speed
Configure the jog speed in an upward motion
0.1 to 1200
mm/min
0.004 to 47.24
Inch/min
Down Speed
Configure the jog speed in a downward motion
0.1 to 1200
mm/min
0.004 to 47.24
Inch/min
Tension Limit
Configure the tensile force limit while in jog mode 0 to +200 N
Compression Limit
Configure the compressive force limit while in jog mode 0 to -200 N
Tare AFG/AFTI
Configure whether or not the AFG/AFTI is tared when
pressing the tare button in jog mode.
Yes or No
