32 Mecmesin MultiTest-dV Operating Manual
Settings: Units
Within the units menu, you can configure the test stands units for displacement and
speed. Force units are configured using the AFG.
Setting Units Available
Displacement mm, in
Speed mm/min, mm/sec, in/min, in/sec
Force N, gf, kgf, ozf, lbf, mN, kN
Settings: Edit Test
Important
For more information relating to ‘Start Direction’ and ‘Move to Start’, please see
MultiTest-dV Operation Sequence and Move to Start.
Displacement
In a displacement test, the crosshead moves between two reference points that are
relative to tared zero. Ensure that the limit switches allow the required travel.
Setting Options
Cycle Count 0-9999
Up Speed 0-1200mm/min
Down Speed 0-1200mm/min
Upper Displacement
A positive displacement is above tared zero and a negative value is
below. Available displacement depends on the test setup.
Lower Displacement
A positive displacement is above tared zero and a negative value is
below.
