kN 0.5 1.0 2.5
kgf 50 100 250
lbf 110 220 550
Displacement
Crosshead travel* 1200mm (47.3”) 1000mm (39.4”) 500mm (19.7”)
Maximum headroom* 1230mm (48.4”) 1030mm (40.6”) 530mm (20.9”)
Displacement resolution 1 µm (0.000025")
Displacement accuracy ±0.130mm per 300mm travel (±0.005" per 11.81")
Speed
Speed range†
mm/min 0.01 to 1200 0.01 to 1200 0.01 to 1200††
in/min 0.004 to 47.2 0.004 to 47.2 0.004 to 47.2
Speed accuracy ±0.2% of indicated speed or ±20 μ/min whichever is greatest
Resolution 0.1mm/min (0.004"/min)
Maximum number of cycles per test 9999 (Cycling testing is not avaliable in dV(u) mode)
Height 1710 mm (67.3") 1510 mm (59.4") 941 mm (37")
Width 290 mm (11.4") 290 mm (11.4") 290 mm (11.4")
Depth 414 mm (16.3") 414 mm (16.3") 414 mm (16.3")
Vertical daylight* 1359 mm (53.5") 1159 mm (45.6") 590 mm (23.2")
Throat Depth** 70.5 mm (2.8”) 70.5 mm (2.8”) 70.5 mm (2.8”)
Weight 26 kg (57 lbs) 25 kg (55 lbs) 24 kg (53 lbs)
Electrical supply
Voltage 230 V AC 50 Hz or 110 V AC 60 Hz
Maximum power requirement 120W 200W 250W
Advanced Force Gauge (AFG), 10 models from 2.5 N to 2500 N
Sensor measurement accuracy 0.1% of full-scale
Enhanced Load Sensors (ELS), 13 models from 2.5 N to 2500 N
Sensor measurement accuracy ±0.5% of reading down to 5% of range
Environment specification
Operating temperature 10°C – 35°C (50°F – 95°F)
Operating relative humidity Normal Industry and laboratory conditions
Display & Data Output
Front Panel Display Indication Load / Displacement / Speed
Output of Test Results
Stand
Via USB (VectorPro™ Software - PDF, XLXS, CSV, TXT, Email and Images)
AFG / AFTI Via Cable (sales@mecmesin.com)
* Measured with force gauge and short extension rod fitted
** Measured on centreline of gauge/sensor
† Where mains voltage is reliable
†† 2.5 kN : recommended maximum speed = 750 mm/min (30 in/min) above 2 kN
