MultiTest-dV Operating Manual Mecmesin 33
Setting Options
Start Direction Choose whether the test direction is upward or downward.
Move to Start Select if the test moves to the start position first.
Example
Upper displacement: +10 mm
Lower displacement: –20 mm
Initial stroke: Up
Move to Start: Yes
Unless already at -20 mm the crosshead will first travel to that point. The stand will then
move to 10 mm above tared zero, followed by a final movement back to -20mm.
AFG Control/Force Control
The AFG control test operation consists of two main functions:
AFG Control - Control of the test stand using the AFG’s limit or break settings,
Force Control - Control of the test stand using the front panel to program limit,
break or cycle settings,
Within AFG Control/Force Control there are four subtests:
Sub-Test Description
AFG Control
Move in a set direction until a force limit or break condition is hit
and then stop. Configured using the AFG.
Force Limit
Move in the configured direction until a force limit is hit and then
stop. Configured using the front panel.
Force Cycle
Cycle between a limit force and a return force. Configured using
the front panel.
Break
Move in the configured direction until a break condition is detected.
Configured using the front panel.
