Medion PC - Connecting the Monitor

C
C
O
O
N
N
N
N
E
E
C
C
T
T
I
I
N
N
G
G
14
Connecting the monitor
Diagram reference: W, W2
If your graphics card has two VGA sockets, you can use either
port to connect to the monitor. Your PC may optionally be
equipped with a digital connector (DVI, W2). You will be able to
connect the VGA plug of your monitor to the DVI connection with
the help of an adapter (not in the scope of the delivery).
Note
Take care that the connector and the socket fit exactly
to avoid damaging the contacts. Because of its asym-
metric form the plug only fits into the socket in one
position.
1. Connect the data cable of the monitor to the socket on the
graphics card (reference W or W2). If necessary, remove
the white guard-ring on the monitor plug and ensure that
the plug and socket mate together precisely.
2. Hand-tighten the screws on the monitor cable.
Caution!
Your PC monitor is preconfigured for a screen resolu-
tion of 1024 x 768 pixels and an optimal refresh rate
of 75 hz. If your monitor does not support these set-
tings it may become damaged or malfunction during
use. You can change the screen resolution and con-
figuration of your monitor as follows (See also your
monitor's User Manual).
