20
PCs with surround sound
Diagram reference: H, H2, H3, H4, U, U2
(optional feature)
Note
You will find information about placing speakers by
starting the sound software in the task bar.
Connect your surround equipment as follows:
1. Connect the Front speaker to the green socket (reference H).
2. Attach the rear loudspeakers to the connector Rear (Posi-
tion H2).
3. Your centre speaker or subwoofer can be connected to the
socket Centre/Subwoofer (H3).
4. Connect to the optional Back Surround socket (H4) two
more speakers for the back surround.
An (optional) digital audio output (SPDIF) can be connected
to an optical and/or a coaxial cable.
1. Plug the Cinch cable to the socket at Position U. Connect the
optical cable to Position U2.
2. Connect the other end of the cable to an audio device with a
corresponding digital input.
