Medion PC - Antenna Connection for Tv;Radio Receiver; TV-Out

C
C
O
O
N
N
N
N
E
E
C
C
T
T
I
I
N
N
G
G
22
TV-out
Diagram reference: V
(optional feature)
If your computer’s graphics card is equipped with a TV-Out socket
you can establish a connection to a TV. You will be able to use a
composite cable (Cinch) or an S-video cable.
1. Connect your PC and your television with the cord required
(available separately) for your TV.
Antenna connection for TV/radio receiver
Diagram reference: Y, Y2
(optional feature)
Should your PC be equipped with a TV-Radio tuner card, then you
must connect the corresponding 75 Ohm coaxial cables (aerial or
cable) for radio and TV reception.
1. Connect a projecting radio aerial to the matching connection
(Y) on the TV card.
2. Connect a terrestrial aerial or cable television to the TV
socket (Y2) of your TV card.
