Modem connection
Diagram reference: Z
(optional feature)
Connect the modem cable as follows, if your PC is equipped with
an analogue modem card:
1. The RJ11 plug is plugged into the modem of your PC.
2. The TAE plug fits an N-coded, analogue telephone socket.
Attention!
Please observe that the modem may only be con-
nected to an analogue telephone line. The connection
of a digital system (ISDN etc.) to an analogue tele-
phone line can possibly cause damage to the modem
or the connected devices and the telecommunication
network.
Connecting speakers/audio output
Diagram reference: H
Here you can connect your headphones, active speakers or
audio connection cables for recording. Please refer to the user's
guide of your stereo installation for information about which con-
nector you should use (usually Line In or Aux).
1. Connect your headphones or active speakers by plugging
the cable with the 3.5 mm stereo jack plug into the green
socket (reference H).
