24
s p e c i fied; Crest Factor: <3:1 at full scale, and <6:1 at half scale.
**Specified from 10% to 100% of range.
***Specified from 15% to 100% of range.
mA µA Overload Protection: 0.63A/500V Fuse, Interrupt Rating 200kA
A Overload Protection: 15A/600V Fuse, Interrupt Rating 100kA
d.c. Current
mA µA Overload Protection: 0.63A/500V Fuse, Interrupt Rating 200kA
A Overload Protection: 15A/600V Fuse, Interrupt Rating 100kA
*10 A continuous; 20 A for 30 seconds maximum, 5 minutes cool down
interval.
Frequency
Sensitivity: 5 Hz–100 kHz* >200 mV
rms
<20 V
rms
100 kHz-500 kHz >400 mV
rms
<20 V
rms
500 kHz–2 MHz >850 mV
rms
<20 V
rms
2 MHz–4 MHz >1 V
rms
<20 V
rms
*Pulse Width >3 µs in this frequency range.
Update Rate: 1.2 per second nominal
Temperature Coefficient: 0.05 x (specified accuracy)/°C @(0°C-18°C or
28°C-50°C)
Overload Protection: 600 V d.c./V a.c. rms
Frequency & a.c.V or a.c. ADP in Dual Display
Sensitivity*: 5 Hz–100 Hz** >15% full scale of a.c. range
100 Hz-1 kHz >20% full scale of a.c. range
1 kHz-10 kHz >35% full scale of a.c. range
10 kHz-20 kHz >50% full scale of a.c. range
Electrical Specifications
Range M8035 M8037* Burden Voltage
Accuracy
400.0 µA 0.4%+4d 0.15 mV/µA
4000 µA 0.2%+2d 0.15 mV/µA
40.00 mA 0.4%+4d 3.3 V/mA
400.0 mA 0.2%+3d 3.3 V/mA
4.000 A 0.8%+4d 0.03 V/A
10.00 A* 0.4%+4d 0.03 V/A
Range M8035 M8037
Accuracy
9.999 Hz, 999.99 Hz, 9.9999 kHz
0.002%+3d
99.999 kHz, 999.99 kHz, 4.0000 MHz
Range M8035 M8037
Accuracy
99.99 Hz, 999.9 Hz, 9.999 kHz, 20.00 kHz 0.002%+1d
