Megger M8035 - Page 25

25
*a.c. V 750 V range: 5 Hz–100 Hz >420 V a.c.
100 Hz–1 kHz >550 V a.c.
**Pulse Width >3 µs in this frequency range.
Update Rate: 1.3 per second nominal
Duty Cycle
Input Frequency: 50 Hz-300 kHz; 5 V Logic Family
Pulse Width >2µs
Update Rate: 1.2 per second nominal
Overload Protection: 600 V d.c./V a.c. rms
Capacitance
* Accuracies with film capacitor or better.
** Specified from 10% to 100% of range.
Overload Protection: 600 V d.c./V a.c. rms
Ohms
Open Circuit Voltage: <1.3 V d.c. (3 V d.c. for 40 Ω & 400 Ω ranges)
Temperature Coefficient: 0.1 x (specified accuracy)/°C at (0°C-18°C or
28°C-50°C)
Overload Protection: 600 V d.c./V a.c. rms
Diode Tester
Overload Protection: 600 V d.c./V a.c. rms
Range M8035 M8037
Accuracy
40.00 Ω 0.2%+6d
400.0 Ω, 4.000 kΩ, 40.00 kΩ, 400.0 kΩ 0.15%+2d
4.000 MΩ 0.3%+2d
40.00 MΩ 1.5%+5d
400.0 ns 0.7%+5d
Range M8035 M8037
Accuracy*
4.000 nF** 4.0%+10d
40.00 nF 3.0%+5d
400.0 nF 3.0%+5d
4.000 µF 0.8%+3d
40.00 µF 2.0%+5d
40.00 µF 5.0%+5d
4.000 mF 5.5%+5d
40.00 mF 6.0%+5d
Range M8037
Accuracy
0.1%–99.9% 0.5d/kHz+2d
Range Accuracy Test Current Open Circuit
(Typical) Voltage
4.000V 2%+1d 0.8mA <3.5V d.c.
