Megger M8035 - Page 26

26
Audible Continuity Tester
Audible threshold: the beeper sounds if the measured resistance is
lower than 10 Ω, and turns off when greater than
60 Ω. Response time <150 s.
Overload Protection: 600 V d.c./V a.c. rms
d.c. Adaptor
10 counts per 1 mV d.c.
Accuracy: 0.08%+1d
Input Impedance: 1000 MΩ, 70 pF nominal
Temperature Coefficient: 0.05 x (specified accuracy)/°C @ (0°C-18°C
or 28°C-50°C)
Overload Protection: 600 V d.c./V a.c. rms
a.c. Adaptor
10 counts per 1 mV a.c.
Accuracy: Same as a.c. 400.0mV range
Input Impedance: 1000 MΩ, 70 pF nominal
Temperature Coefficient: 0.1 x (specified accuracy)/°C @ (0°C-18°C or
28°C-50°C)
Overload Protection: 600 V d.c./V a.c. rms
dBm (M8037 only)
At 600 Ω, -2.21 dBm to 54.25 dBm
Accuracy: ±0.25 dB + 2d (@40 Hz-20 kHz)
Selectable reference impedance of 4, 8, 16, 32, 50, 75, 93, 110, 125,
135, 150, 200, 250, 300, 500, 600, 800, 900, 1000, 1200 Ω
Input Impedance: 10 MΩ, 30 pF nominal
Update Rate: 1.1 per second nominal
Overload Protection: 780 V rms/1000 V peak
RECORD mode
Nominal Response for d.c.: 50 ms to 80%, 100 ms to 99%
Nominal Response for a.c.: 50 ms to 80%, 100 ms to 95%
Accuracy: Specified accuracy ±10 digits for changes >200 ms in
duration (±40 digits in a.c.); 1.5 s autoranging buffer (except
Cx, a.c.+d.c. V)
CREST mode
Accuracy: Specified accuracy ±220 digits for changes >0.8 ms in
duration
SORT mode
Nominal sort rate: 0.2 s (except Cx, a.c.+d.c. V)
Accuracy: Specified accuracy ±5 digits
Electrical Specifications
