Function
code
Name
Index-
Sub-index
Value range
Min. unit
Default
value
Menu
mode
Cha
nge
Q
B
upon stop
0: Frequency retained
upon stop
1: Frequency cleared upon
stop
Note:
The ones place and tens
place are only for
P02.04=0, 1, 2
The hundreds place and
thousands place are only
for P02.07=1, 2, 3
P02.07
Source of
auxiliary
frequency
reference
2002-08h
0: No auxiliary reference
1: Digital setting 1: Keypad
∧∨
2: Digital setting 2:
Terminal UP/DN
3 to 5: Reserved
6: Process closed-loop PID
7: Reserved
1
0
×
√
○
P02.08
Digital setting
of auxiliary
frequency
reference
2002-09h
0.00 to 3000.0 Hz
0.01 Hz
0.00
×
√
○
P02.09
Auxiliary
reference
coefficient
2002-0Ah
0.00 to 9.99
Only valid for P02.07=4 to
7
0.01
1.00
×
√
○
P02.10
Source
calculation of
frequency
reference
2002-0Bh
0: +
1: -
2: *
3: MAX (Main, Auxiliary)
1
0
×
√
○
