Megmeet SPS-NE Series User Manual

37
P02.04
Source of main
frequency reference
0: Digital setting 1: Keypad ∧/∨
1: Digital setting 2: Terminal UP/DN
2 to 5: Reserved
6: Process closed-loop PID
7 to 10: Reserved
0
○
In speed control, set P30.00=0 first.
Acceleration/Deceleration time
Function
code
Name
Value range
Default value
Change
P02.13
Acceleration
time 1
0.0 to 3600.0 s
6 s
○
P02.14
Deceleration
time 1
0.0 to 3600.0 s
6 s
○
The specific acceleration/deceleration time shall be determined by the actual requirements on the device.
If the device needs to be stable during acceleration and deceleration:
Increase P02.13 (acceleration time 1) and P02.14 (deceleration time 1).
If the device needs to be quickly accelerated and decelerated:
Too short acceleration and deceleration time will cause overcurrent during acceleration (Er.oC1) and overvoltage
during deceleration (Er.oU2). Thus, well-matched resistors are required, and dynamic braking should be enabled
through the function code.
Dynamic braking
Function
code
Name
Value range
Default value
Change
P08.21
Dynamic braking usage
ratio
0.0 to 100.0% (0.0: no action)
100.0%
○
P08.22
Braking startup voltage
700 to 780 V
720
○
