3 Setup and installation
15
Pos. Description Art. no. Note
3.3 Filter for MELAdem ME48240 included in ME01049
4 MELAjet spray pistol ME27300 optionally available to order
4.1 PUR hose (6/4mm, MELAjet hose) ME28820 included in ME27300
4.2 Feed water inlet connection (swivel screw connection)
MELAjet
ME53465 included in ME27300
5 Wall outlet NW40 -- on-site
6 Double-chamber siphon ME26635 optionally available to order
7 Double support sleeve for an existing trap (optional) ME37400 optionally available to order
8 Wastewater hose for pressure release 41B+ (Evo)/43B+
(Evo)
ME39181 optionally available to order
8.1 Hose PTFE (8/6 mm, 5 m, wastewater hose) ME39180 included in ME39181
8.2 Wastewater adapter (G1/4” internal thread) ME56930 included in ME39181
9 Threaded connection 1/4”, angle, for hose 8/6 mm (pressure
release connection)
ME53471 present on device-side
10 Water tap with safety combination -- on-site
11 Water stop (leakage water detector with shut-off valve and
probe)
ME01056 optionally available to order
12 Mains connection -- on-site
Example 3: Using the MELAdem 47 reverse osmosis unit
The reverse osmosis unit is connected directly to the feed water inflow of the steam sterilizer and uses normal tap water
to generate demineralised water.
NOTICE
When connecting an external feed water supply it is necessary to connect an external wastewater
outflow as well.
There is a risk that hot wastewater might run through the emergency overflow.
To convert to the feed water supply from a water treatment unit, make the following preparations:
1. Empty both chambers of the internal storage tank.
2. Replace the feed water inflow fitting located on the steam sterilizer with the banjo bolt with feed water inflow fitting
for hose Ø6x1 (art. no. ME25655) because of the different hose diameter. Both parts are included in the water
connection set (art. no. ME09034). When using a MELAjet spray pistol use the swivel screw connection (art. no.
ME53465).
3. Replace both Cu seals (art. no. ME42360, included in the scope of delivery) for the hollow screw.
In this example, the used feed water (wastewater) is fed via the one-way outlet drain into the siphon of the domestic
water network. To do this, connect the outlet hose and mount it to the double-chamber siphon via the double hose
nozzle.
When connecting the water treatment unit directly to the domestic water network, MELAG recommends the additional
installation of the leakage water detector (water stop) with shut-off valve and probe.
