2 Installation requirements
7
Requirements for installing the device
If it is absolutely necessary to install the device, implement one of the following measures:
1. It must be possible to pull out the device for operation (pos.a).
2. In the installation space, there must be an exhaust shaft in the rear area that discharges the warm air upwards
(pos.b).
3. There must be an exhaust shaft in the rear area of the installation space that actively discharges the warm air to the
rear (pos.c).
4. Switching off the DRYtelligence (menuSettings >Intelligent drying).
Additional space requirement for the feed water supply
Additional space is required for a storage container or a water treatment unit. It is also necessary to guarantee free
access to the hoses and cables leading from the steam sterilizer to the water treatment unit.
Space requirements MELAdem 40 MELAdem 47
Water treatment unit Pressure tank
Width 32 cm 40 cm --
Height 35 cm 46 cm 40 cm
Depth 16 cm 18 cm --
Diameter -- -- approx. 28 cm
Mains supply
Implement the following safety measures when dealing with the cable and power plug:
n Never damage or alter the power plug or cable.
n Never bend or twist the power cable.
n Never remove the plug by pulling on the power cable. Always take a grip on the plug.
n Never place any heavy objects on the power cable.
n Never run the power cable over areas in which it could become trapped (e.g. doors or windows).
n Never lead the cable along a source of heat.
n Never use any nails, paper fasteners or similar objects to fix the cable.
n Should the power plug or cable suffer damage, switch off the device. The power cable or plug should only be
replaced by authorised technicians.
n The mains socket must be freely accessible after installation so that the device can be disconnected from the
electrical mains at any time if necessary by pulling the mains plug.
