2 Installation requirements
8
Building-side requirements of the mains connection
Property On-site requirements
Electricity supply Socket with 220-240 V, 50/60 Hz
Electrical power 2800 W
Max. voltage range 207-253 V
Building fuses A separate circuit with 13A, RCD 30mA (to guarantee continued practice operation
during steam sterilizer malfunction)
Other additional socket 230V, 50Hz for MELAprint60 label printer, MELAprint42/44 log
printer etc.
Length of the power cable 2 m
Water connection
Observe the following requirements for the water connection if there is no manual filling or emptying.
Feed water Wastewater
Connection in the practice via a water treatment unit, e.g.
MELAdem
via the one-way drain, e.g. with the water
connection set
Wall outlet, nominal width 40 or to a
U-trap (flush outflow)
Installation height -- min. 30 cm under the steam sterilizer
Min. flow pressure 1.5 bar at 3 l/min --
Recommended flow pressure 1.5-4 bar at 1.4 l/min --
Min. static water pressure 2bar --
Max. static water pressure 10 bar --
Max. water temperature 35 °C 98 °C
Water quality distilled or demineralised water in ac-
cordance with EN 13060, Appendix C
--
Measures for protecting the drink-
ing water
none (internal precautions against back-flow into the drinking water supply via
safety combination consisting of a back-flow preventer and pipe aerator; secured in
accordance with EN 1717)
Leakage water detector MELAG recommends the installation of a leakage water detector with a cut-off valve
(e.g. MELAG water stop).
At first commissioning, the DAC Premium Plus consumes 3.5 l of feed water (in accordance with EN13060, Appendix C)
once to fill the double jacket.
