Melitta Caffeo - Description of the Appliance; Legend for Fig. a; Legend for Fig. B

ENGLISH
45
3 Description of the appliance
Legend for Fig. A
Fig. number Explanation
1
Drip tray with cup plate and coffee grounds container
(interior)
2 "Perfect Cappuccino" milk frother
3 Water reservoir
4
Button for brewing strength
5
Button for steam dispensing
6 Valve switch
7 Display
8 2-chamber "Bean Select" bean container
9 Rocker switch for "Bean Select" bean container
10 Ground coffee chute with lid
11
On/off button
12 Coffee quantity regulator
13
Button for single-cup dispensing
14
Button for two-cup dispensing
15 Height-adjustable coffee outlet
16 Float for the water level indicator in the drip tray
Legend for Fig. B
Fig. number Explanation
17 Power-supply cord
18 Brewing unit and type plate (behind the cover)
19 Grinding fineness adjustment
20 Power switch
