ConnectX®-3 Ethernet Single and Dual QSFP+ Port Adapter Card User Manual Rev 2.0
Mellanox Technologies
15
3 Hardware Installation
3.1 System Requirements
3.1.1 Hardware
A system with a PCI Express x8 slot is required for installing the card.
3.1.2 Operating Systems/Distributions
Please refer to Section 1.3, “Operating Systems/Distributions,” on page 11.
3.1.3 Software Stacks
Mellanox OpenFabric software package - MLNX_EN for Linux, WinOF for Windows and ESX
5.1 for VMware. See Chapter 4, “Driver Installation”.
3.2 Safety Precautions
1. Remove any metallic objects from your hands and wrists.
2. Make sure to use only insulated tools.
3. Verify that the system is p
owered off and is unplugged.
4. It is strongly recommended to use an
ESD strap or other antistatic devices.
3.3 Pre-installation Checklist
1. Verify that your system meets the hardware and software requirements stated above.
2. Shut down your system if active.
3. After shutting down the system, turn of
f power and unplug the cord.
4. Remove the card from its package. Please note that the ca
rd must be placed on an antistatic
surface.
5. Check the card for visible signs of damage. Do
not attempt to install the card if damaged.
3.4 Bracket Installation Instructions
The card is usually shipped with a tall bracket installed. If this form factor is suitable for your
requirements, you can skip the remainder of this section and move to Section 3.5, “Card Installa-
tion Instructions,” on page 18. If you need to replace it with the short bracket that is included in
the shipping box, please follow the instructions in this section.
To replace the bracket you will need the following parts:
• The new bracket of the proper height
• One new gasket
The adapter is being installed in a system that operates with voltages that can be lethal.
Before opening the case of the system, observe the following precautions to avoid
injury and prevent damage to system components.
