ConnectX®-3 Ethernet Single and Dual QSFP+ Port Adapter Card User Manual Rev 2.0

Mellanox Technologies

7.5 Bracket Mechanical Drawing

Figure 11: Dual-port Bracket

Figure 12: Single-port Bracket

Port 2

Port 1

LEDs

Gasket

LEDs

Port 1
