ConnectX®-3 Ethernet Single and Dual QSFP+ Port Adapter Card User Manual Rev 2.0

Mellanox Technologies

7.4 Board Mechanical Drawing and Dimensions

Figure 9: Mechanical Drawing of the Single-port MCX313A-BCBT Adapter Card

All dimensions are in millimeters.

All the mechanical tolerances are +/- 0.1mm.

142.24

53.59

40.5

49.09

45.95

12.75

22.61

J1 - I

C Connector

Flash Jumper
