To mount the system into the rack:
Attach the left and right rack mount rails (A) to the switch, by gently pushing the switch chassis’ pins through the slider key
holes, until locking occurs.
Secure the chassis in the rails by screwing 2 flat head Phillips screws (E) in the designated points with a torque of 1.5±0.2
Nm.
At least two people are required to safely mount the system in the rack.
