Memotec NetPerformer SDM-9220

Hardware Installation
Memotec Inc. 3-23
2. Carefully insert the SDM-9220/9230 unit with the attached brackets into the rack.
Secure the front of each bracket onto the rack using two mounting screws with
washers, as shown in Figure 3-14
.
Figure 3-14: Completed Rackmount Installation
Four mounting screws securely hold unit in place
