Product Description
Memotec Inc. 4-7
4.4 SDM-9140 Base Unit
4.4.1 Front View of the SDM-9140 Base Unit
Figure 4-5: Front View of the SDM-9140s
1 Interface card slots (4) 6 USB port 11 Wireless status LED
2 Interface status LEDs 7 Console port 12 GPS antenna connector
3 Gig Ethernet ports (2) 8 Power supplies status LEDs 13 Wireless antenna connector
4 LAN status LEDs 9 GPS status LED
5 Serial port 10 System status LEDs
1
2
3 4
5 6
7 9 11
13
8 10
12
4
1 Interface card slots (4) 5 Gig Ethernet ports 3-8
(RJ45/LAN switch)
9 Console port 13 Wireless status LED
2 Interface status LEDs 6 LAN status LEDs 10 External clock In/Out 14 System status LEDs
3 Gig Ethernet ports 1-2
(SFP option)
7 Serial port 11 GPS status LED 15 Wireless antenna
connector
4 Gig Ethernet ports 1-2
(RJ45)
8 USB port 12 Power supplies status
LEDs
16 GPS antenna
connector
Figure 4-6: Front View of the SDM-9140e
1
2
43 13
8 10 12 146
16
11
9 155
7
