NetPerformer Hardware Installation Guide
4-8 Memotec Inc.
4.4.2 Rear View of the SDM-9140 Base Unit
Figure 4-7: Rear View of the SDM-9140 with UAC Power Supply Options
1 Cooling fans (3) 3 90-264 VAC Single Power Supply, 47-63 Hz
2 Ground lug 4 Hot-Swap Redundant AC Power Supply 1+1
(90-264 VAC, 47-63Hz)
1 2
3
4
