4.2 SDM-9120 Base Unit
4.2.1 Front View of the SDM-9120 Base Unit
4.2.2 Rear View of the SDM-9120 Base Unit
Figure 4-1: Front View of the SDM-9120
1 System status LEDs 5 Serial port
2 Interface card slots 6 Console port
3 Ethernet ports (2) 7 Power supply
4 LAN status LEDs 8 Ground lug
Figure 4-2: Rear View of the SDM-9120
Item Details
Base unit chassis, with two slots for interface
cards
“Base Unit Chassis” on page 4-11
Two Ethernet ports (require customer-supplied
LAN cables)
“Ethernet Ports” on page 4-13
One serial port (requires custom serial cable) “Serial Port” on page 5-3
One console port, with console cable “Console Port” on page 4-15
Table 4-1 Basic Features of the SDM-9120 Unit
