13
FV36 85-03-01014
SPECIFICATIONS
General Specifications
FIREPLACE OVERALL DIMENSIONS: 46 ⅝” wide x 40 ½” high x 19 ½” deep
MINIMUM FRAMING DIMENSIONS: 50” wide x 41” high x 20” deep
GLASS SIZE: Neoceram glass with non-reflective coating. Visible glass measures 720 in
2
(33 ½” W x 21 ½” H).
MANTEL ALLOWANCE: 8” deep mantel at 22” above top convection opening.
VENT SYSTEM ALLOWANCE: Top vent only: 5” exhaust and 8” combustion air intake coaxial vent pipe
required.
9” vertical minimum with 6” to 12” horizontal. 40’ vertical maximum. 32’ maximum horizontal run allowed
with 4’ minimum vertical starter section.
CONTROLS: IPI electronic ignition system with AC primary power and DC backup power. Accent light and
blower operate on AC power only. Thermostatic remote control with Smart Thermostat mode included.
BLOWER SYSTEM: 105 CFM high-efficiency motor dual blower system. 120VAC, 2Amps. Six speed control
settings with remote control.
ACCENT LIGHT SYSTEM: Accent light system included and can be turned on or off or dimmed using remote
control.
BURNER SYSTEM: Dual 304 stainless steel tubular burners.
BURNER AIR SHUTTER SYSTEMS: Externally controllable rear and front burner air shutters.
NATURAL GAS INFORMATION: Factory equipped for natural gas. 5” WC minimum inlet pressure required.
For natural gas applications, front burner orifice size is #44, and the rear burner orifice size is #38.
LP GAS INFORMATION: LP conversion kit #HA-110-00084 is required. 12” WC minimum inlet pressure
required. For LP gas both front and rear burner orifices #54.
