Mendota FV36 - Fireplace and Framing Dimensions

16
FV36 85-03-01014
Fireplace Dimensions
A
19 1/2
UNIT DEPTH
40 1/2
UNIT HEIG HT
9 3/8
10 3/4
5 7/8
11 1/2
ELEC TRICAL SUPPLY INLET
110 VAC
GAS SUPPLY IN LET
1
2
" FN PT
32 5/8
FLOOT TO V ENT
STARTER TOP
42
UNIT W ID TH AT FORNT
46 5/8
OVERALL UNIT W IDTH
1 1/2
FLOOR TO BO TTOM
FIN ISHING GUIDE
25 1/8
FIN ISHING GUIDE
HEIGHT
37 1/8
FIN ISHING GUIDE
WIDTH
5" X 8" COAXIAL
STARTER COLLA R
HEAT TRA NSFER
DUCT KN OCKOUT
SYNC SW ITCH
MASTER SW ITCH
(UP - UNIT ON)
(D OWN - UNIT OFF)
10 3/8
21
